MISTER HITCHES RAPTOR 4500KG SUPER DUTY ADJUSTABLE BALL MOUNT 16 STAGE
$331.99
THIS NEW RAPTOR DESIGN HAS BEEN MADE ESPECIALLY FOR VEHICLES HAVING A SHALLOW TOW BAR RECIEVER EG. PAJERO SPORT OR FORD RANGER.
ALSO SUITABLE WERE A SHORTER SHANK IS REQUIRED.
Availability:
Out Of Stock
Sku: MHABM45-S4
MISTER HITCHES RAPTOR 4500KG SUPER DUTY ADJUSTABLE BALL MOUNT 16 STAGE (MHABM45-S4)
FEATURES:
- 4,500kg MAX. TOW CAPACITY. 450kg MAX. T.W.
- TESTED & COMPLIANT WITH ADR62/02.
- TESTED UP TO 6,750kg (LONGITUDINAL TENSION).
- SOLID STEEL SHANK WITH DUAL GUSSETS FOR SUPERIOR STRENGTH.
- INCLUDED IS A TOW BALL REDUCING BUSH & WASHER SUITS 50mm OR 70mm TOW BALLS. (tow balls sold separatly)
- REVERSIBLE SHANK & BALL PLATFORM GIVE GREATER DROP OR RISE HEIGHT.
- 16 STAGE ADJUSTMENTS MAX RISE 188mm MAX DROP 210mm. (32mm increments)
- OPTIONAL SHANKS CAN GIVE A DROP OF 370mm & RISE UP TO 350mm
- PIN HOLE TO BALL HOLE: 267mm. PIN HOLE TO END OF SHANK: 40mm
- H.T. 3/4” BOLTS, NYLOC LOCKING NUTS AND TOOTHED CONICAL WASHERS GIVES SUPERIOR STRENGTH.
- POWDER COATED ENAMEL FINISH GIVES GREATER PROTECTION FROM THE ELEMENTS.
- COMPATIBLE WITH DO35 & DO45, TREG, McHITCH, ALKO & ARK COUPLINGS.
- DESIGNED & MANUFACTURED TO MISTER HITCHES STRICT QUALITY AND SPECIFICATIONS.
THIS NEW RAPTOR DESIGN HAS BEEN MADE ESPECIALLY FOR VEHICLES HAVING A SHALLOW TOW BAR RECIEVER EG. PAJERO SPORT OR FORD RANGER.
ALSO SUITABLE WERE A SHORTER SHANK IS REQUIRED.
