240VAC 24V 40A IP65 Lithium
LiFePO4 Battery Charger

Item Specification Description/Remark
Model AT-240-IP65-2440ALFPV01

24V 40A IP65 LiFePO4 Battery
Charger
Input Voltage min 200Vac to max 260Vac
Input Power Max 1408W
Weight 7.5kg
Dimensions

310mm×230mm×101mm
(LxWxH)

Constant charge voltage Vdc 29.2V
Constant charge current Min 38A to max 42A
Charge complete current Vdc min 3A to max 3.4A 8% of Constant Current
Ripple voltage 500mV
Standard capacity(0.2C5A) 100 Ah / 1280Wh
Efficiency 88% At full load
