MISTER HITCHES 12 STAGE ADJUSTABLE BALL MOUNT 4T SUITS FORD RANGER - MHABM-5XHDS

Due to many requests, Mister Hitches has now developed a short shank version of their ever-popular MHABM-5XHD.

The shorter shank is also suitable for a short-shanked tow bar e.g. Ford Ranger. This hitch has a 25mm x 75mm ball platform and is one of only a few ball mounts that is suitable for the Stone Stomper.

The hitch is fully reversible which gives 12 mounting adjustments. Dual 10mm gussets, a 5.75mm thick shank wall & H.T. 12.9-grade mounting hardware makes this one of the strongest & most versatile hitches on the market.

• G.T.W. 4000kg T.W. 400kg
• Pin hole to ball hole 262mm
• Pin hole to gusset 70mm
• 12 adjustable positions
• Drop 80-186mm Rise 50-160mm
• 5.75mm Thick walled steel shank, robotic welded for strength
• Dual 10mm Gussets
• High Tensile 12.9 Grade bolts
• Seaguard matte black powder coat finish gives superior corrosion protection
• Complies to the testing requirements of ADR & Australian Standards where applicable
• Fits 2" x 2" Towbar receivers (50mm)
• Ball Hole size 7/8"
• Compatible with DO35 Pin
• Do not overload
