Solarking 150Ah 12V Lithium LiFePo4 Battery High Output 150A 6375C

New 2021 Solarking Designed High Output Lithium Battery - 150A Continuous Discharge with Advanced Active Cell balancing BMS - 150Ah Battery capacity - All housed in a compact battery casing measuring 385x205x283

For those thinking it's about time to jump ship to Lithium LifePo4 Batteries - Solarking Lithium Batteries now offer an all new High Output 12V Lithium Battery Range. A trusted Australian Distributor these batteries offer 3YR WARRANTY & ARE ULTRA LIGHTWEIGHT. Solarking Lithium Batteries can be connected in series or parallel.

The Solarking CB-150-12-150 now features a 150A BMS with Active Cell Balancing. This balancing technique redistributes charge between battery cells during the charge and discharge cycles, thereby increasing system run time by increasing the total useable charge in the battery stack, decreasing charge time compared with passive balancing, and decreasing heat generated while balancing.

SolarKing Lithium batteries are fully sealed with a built in battery management system (BMS) to make sure the battery operates safely. Perfect replacement or upgrade for a traditional lead acid batteries and the life of lithium batteries is up to 3 times the life of lead acid batteries. Lithium batteries have a much greater depth of discharge capacity and are less than half the weight of lead acid deep cycle batteries.

TCA also stock an excellent range of compatible AC and DC to DC Chargers with Lithium Battery charging profiles. This battery would also be an ideal fit for our range of Arkpak Portable Power Battery Boxes

If you have any questions regarding our range of batteries for caravans, campers, marine, camping or home storage applications please call us on 0458 220 765. Our staff will be able to tailor a package for all types of applications and budgets.

Solarking CB-150-12-150 Features:

150AH Lithium Iron LiFePo4
2000 Cycles @ 100% DOD
150A HIGH RATE CONTINOUS DISHCHARGE
Built in advanced Battery Management System (BMS) with Active Cell Balancing
Lightweight
Can be connected in series or parallel
Equivalent to 3 150AH deep cycle lead acid batteries
3 Year Warranty

CB-150-12-150 Specifications:

Dimensions: 385x205x283
Chemical: Lithium Iron LiFePo4
Product Weight: 18.2kg
Voltage: 12.8VDC
Battery Capacity: 150AH
Max Discharge Rate Continuous: 150A
Max Discharge Rate 3 Second Pulse: 225A
Nominal Charge Rate: 30A
Max Charge Rate: 75A
Min Charge Rate: 1A
Bulk Charge Setting: 14.6V
Float Setting: 13.6V
Max Charge Voltage Cut Off: 15.2V
Active Cell Balancing: 5AH Nominal (8AH Peak) Charge & Discharge Cycles
Cycles @ 100% DOD: 2000 Cycles
Cycles@ 80% DOD: 3000 Cycles
Cycles@ 50% DOD: 4000 Cycles
Cycles@ 30% DOD: 8000 Cycles
Low Voltage cut out: 10.0VDC
BMS reconnect: Automatic
Operating Temperature Range: -20°C ~ +60°C
Maximum In-series voltage: 30.4V
Water/Dust Rating: IP-65
Self-Discharge : Less Than 3% Per Month
Cell Type: Cylindrical
Cell Capacity: 15.5AH
Cell Model: 33135
Cell Quantity: 40pcs
Cell Connection: Laser Welded
Terminal Size: T8 - Side Terminals

CB-150-12-100 Package Includes:

1x 6375C 150AH Solarking LiFePo4 Lithium Battery

Note: This battery is not designed to start motor vehicles.

Solarking 150Ah 12V Lithium Battery LiFePo4 150A BMS Active Cell Balancing
