MISTER HITCHES REPLACEMENT SHANK TO SUIT WDS - 254MM (10") (MHWDS10)

THIS SHANK IS THE STANDARD SHANK FOUND IN MISTER HITCHES WEIGHT DISTRIBUTION KITS.
SUITS MISTER HITCHES WEIGHT DISTRIBUTION SYSTEMS & MULTI-HITCH MIX 'N' MATCH SYSTEM
SUITABLE FOR MISTER HITCHES WEIGHT DISTRIBUTION SYSTEM & MULTI-HITCH MIX 'N' MATCH SYSTEM
THE SHANKS ARE MADE FROM SOLID STEEL.
SUITS FORD RANGER SHORT SHANK RECEIVERS
3 PIN HOLES GIVE GREATER ADJUSTMENT. EG. END OF SHANK TO 1ST HOLE 50MM, END OF SHANK TO 2ND HOLE 82.5MM, END OF SHANK TO 3RD HOLE 125MM.
THESE SHANKS CAN BE DRILLED OR CUT WITHOUT LOSS OF INTEGRITY.
DROP (TOP OF SHANK TO TOP OF WDH BALL PLATFORM) = 63.5MM
RISE (TOP OF SHANK TO TOP OF WDH BALL PLATFORM) = 165MM
SHANK OVERALL HEIGHT = 225MM
SHANK IS SOLID STEEL 50.8MM SQUARE SUITS HAYMAN REESE STYLE TOWBAR RECEIVERS
4.4T RATED - SHANK ONLY
PART NUMBER: MHWDS10
