MISTER HITCHES PINTLE HOOK COMBO - 8 TONNE LOW WEAR

POWDER COATED FINISH
FITS TO PINTLE RECEIVER ARM (MHPRA) OPTIONAL
INCLUDES LOCKING SAFETY CATCH & MOUNTING HARDWARE (4 x GRADE 8 BOLTS & NUTS)
USED IN AGRICULTURE, MINING, 4X4 AND WHERE SHIFTING HEAVY LOADS IS REQUIRED - EG. PLANT TRAILERS
CAN BE USED WITH STANDARD 50MM BALL COUPLINGS OR WITH PINTLE RING
TOW BALL CAPACITY = 3500kg
PINTLE HOOK CAPACITY = 8000kg
MAX. T.W. TONGUE WEIGHT 1360kg
FULLY FORGED LOW WEAR DESIGN
MOUNTING POSTITIONS = 85MM x 45MM x 13.5MM
INSTRUCTIONS AND H.T. HIGH TENSILE MOUNTING HARDWARE INCLUDED
COMPLIES WITH ADR
